thank you for everything.

hi,everyone.
OK. Well, what do I solder the pins.
thanks.

See the photo this way.cable, such as the photo turned upside down.
May need to do another solder pin here?

Hi,thank you so much,all friends.I took your time.Forgive me.My English is not good.Sorry. Photos took in the vertical . It looks like the mirror, see the reverse. My Photos is bad.No mymachine for shooting macro... :) So, I really solder 1,7,9,12 pins. Finally,I take the regular photo on elm327.Add...

I know. Multiecuscan interface types, choose K-line interface. This right?
I do ELM1 (1-7-9-12 solder).Add the photos.Is there anything else?

Hi,I'm again... ((((
ABS,ASR,VDC not connect ELM327. I added Photo .
But,ELM connect to Body computer as finally.(a situation a little better.)
Do you think I take a new wire.
Do you think,I taking to VAGCOM cable for ABS,ASR,VDC.

Thank you for everything.I tried.

Hi. Thank you for answering my questions.
---
I added board photos ELM327.
There are two things in a different resistance.
How do you think?
Do you think should remove R04.Thank you.

I make adapter cable1,but don't use.
I Don't know DIP Switch.
R04 not destroy.
If,I removed r04 ,does it work ELM327.
Thank you for everything.

Hi, I have ELM327 v1.4a.(by on- board.). I've Alfa 147 2.0 Selespeed.I want to connect to Vdc,ABS. multiecuscan.Net -->Supported Vehicles diagrams--> ELM327--> Table Adapter1(ELM1). I do ELM1 (1,7,9,12 pins bridge).But,ELM327->Cannot ecu.Check serialports and pins. I can ecu and automatic transmissi...
